oxford wherry bow fillet

• cr

  constance radke

  7/26/24, 5:34 PM

  hi,

  I was reviewing my work to date against the instructions and available pictures and wanted to confirm how thick/wide/deep the vertical fillet inside the bow should be?  the plans i got did not include any radius call outs for fillet tools, so I used pictures and other boats I'd seen as a guide and all is nice and sturdy.  But then i saw a picture of a finished bow trim with what looks like a huge triangle of epoxy at the tip, and so I wondered if that was just a variation or whether I need to pack more epoxy in there.  the fillet I did is a shy inch deep.

  I need to put in more llet me know,

  -Constance

  0 likes 0 likes Liked Like

  ---

  3
  Posts

  65
  Views

  Reply

  ---

• CA

  Colin Angus

  7/26/24, 7:23 PM

  @constance radke It sounds like your bow fillet will be just fine.  From a structural standpoint, the bow fillet doesn't need to have much more epoxy than the frame/bulkhead fillets.  We do normally recommend using a one inch wide filleting tool to squeeze it in with, but this extra epoxy is more about being able to withstand collisions.  For normal use (assuming no collisions) it's really a little more than required.

  0 likes 0 likes Liked Like

  ---

• cr

  constance radke

  7/26/24, 10:51 PM

  thanks, I did use a 1" radius, but wasn't sure.

  and thank you for the quick response, I appreciate it.

  -C
